AC135 Series Low Frequency Accelerometer, Top Exit Connector / Cable, 500 mV/g
The AC135 is a low‑frequency accelerometer designed for vibration analysis. It features a top‑exit connector, integrated cable shield, and a stainless‑steel 316L case for harsh environments.
Key specifications include a sensitivity of 800 mV/g (±10%), frequency response from 0.2 Hz to 3000 Hz (12‑180,000 CPM), a dynamic range of ±10 g, and operation over –58 °F to 250 °F (–50 °C to 121 °C). Electrical parameters such as a 18 VDC supply, <100 Ω output impedance, and constant‑current excitation of 2‑10 mA are also listed.
| Sensitivity | 800 mV/g (±10%) |
|---|---|
| Frequency Response | 0.2 – 3000 Hz (12 – 180,000 CPM) |
| Dynamic Range | ±10 g peak |
| Temperature Range | -58 °F to 250 °F (-50 °C to 121 °C) |
| Output Impedance | <100 Ω |
| Voltage Source | 18 VDC |
The AC135 operates from 0.2 Hz to 3000 Hz (12 – 180,000 CPM).
The device has a sensitivity of 800 mV/g with a ±10 % tolerance.
It can measure up to ±10 g peak dynamic range.
The accelerometer works from –58 °F to 250 °F (–50 °C to 121 °C).
