The TPR3003T-3C and TPR3005T-3C series are high‑reliability regulated DC power supplies with constant‑voltage/constant‑current (CV/CC) conversion, over‑temperature, short‑circuit, and overload protection. They are suited for labs, electronic production lines, communication equipment maintenance, and other research or teaching environments.
The manual covers installation, wiring, operation modes (independent, series, parallel), current‑limit setting, safety precautions, and maintenance procedures. It also lists technical specifications such as input voltage, output ranges, accuracy, ripple, and environmental limits, helping users configure the unit safely and efficiently. This manual is written in Chinese.
| Operating temperature range | 0 °C ~ 40 °C |
|---|---|
| Storage temperature range | -20 °C ~ 80 °C |
| Dimensions (L×W×H) | 370 mm × 250 mm × 160 mm |
| Output voltage range | 0 V ~ 30 V (continuous) |
| Output current range | 0 A ~ rated value (continuous) |
| Voltage accuracy | ±0.5 % rdg ±2 digits |
| Current accuracy | ±0.5 % rdg ±2 digits |
| Ripple noise (I < 3 A) | < 0.5 mV rms (5 Hz ~ 1 MHz) |
