The PPS300 series are single‑programmable power supplies offering high stability, low ripple and both digital and analog control features. They provide output voltages up to 30 V and currents up to 3 A (PPS3003S) or 5 A (PPS3005S) with a maximum power of 150 W.
The manual explains safety precautions, how to adjust voltage and current using the VSET and ISET keys, storage of settings, and protection mechanisms such as over‑current, over‑voltage and over‑temperature. Interface options, environmental limits and front‑panel layout are also described.
| Output voltage range | 0 ~ 30 V |
|---|---|
| Output current range | 0 ~ 3 A (PPS3003S) / 0 ~ 5 A (PPS3005S) |
| Maximum output power | 150 W |
| Power effect (voltage regulation) | CV < 0.01 % + 3 mV (AC + 5 %) |
| Load effect (voltage regulation under load) | CV < 0.5 % + 10 mV |
| Ripple and noise | < 1.0 mV rms |
| Output accuracy (voltage) | 0.5 % + 2 LSB |
| Output accuracy (current) | 1 % + 5 LSB |
| Read‑back accuracy (voltage) | 0.5 % + 10 LSB |
| Read‑back accuracy (current) | 1 % + 20 LSB |
| Protection functions | Over‑current, over‑voltage, over‑temperature |
| Interface | USB (optional) |
| Operating temperature range | 0 ~ 40 °C |
| Maximum humidity | < 80 % |
The supplies can output voltages from 0 V up to 30 V.
Press the [VSET] key, then turn the knob while the voltage value flickers to set the desired voltage.
It includes over‑current, over‑voltage and over‑temperature protection.
Yes, a USB interface is provided as an optional option for communication.
