MCP606/7/8/9 are operational amplifiers from Microchip Technology Inc. Features low input offset voltage, rail-to-rail output swing capability and low input bias current. Suitable for single-supply, precision, high-impedance, battery-powered applications.
The MCP606/7/8/9 family of operational amplifiers from Microchip Technology Inc. are low‑power, unity‑gain stable CMOS op‑amps with rail‑to‑rail output and low input offset voltage. They are designed for single‑supply, high‑impedance, battery‑powered applications and are available in single, dual, and quad configurations.
Typical applications include battery‑powered instruments, strain‑gauge circuits, medical devices, and test equipment. The devices are offered in PDIP, SOIC, TSSOP, and SOT‑23‑5 packages and operate over an industrial temperature range of –40 °C to +85 °C (extended to +125 °C with reduced performance).
| Supply Voltage | 2.5 V to 6.0 V |
|---|---|
| Input Offset Voltage | 250 µV (maximum) |
| Input Bias Current | 80 pA (maximum at +85 °C) |
| Quiescent Current | 25 pA (maximum) |
| Gain Bandwidth Product | 155 kHz |
| Slew Rate | 0.08 V/µs |
| Rail‑to‑Rail Output | Yes |
| Unity‑Gain Stable | Yes |
The devices operate from 2.5 V up to 6.0 V.
The input offset voltage is specified as 250 µV maximum.
Yes, they feature rail‑to‑rail output swing.
