The TPS62052 is a synchronous step-down converter from TI with high efficiency, low quiescent current, wide operating input voltage range, adjustable output voltage range and more. It is ideal for systems powered from a 1-cell or 2-cell Li-Ion battery or from a 3-cell to 5-cell NiCd, NiMH, or alkaline battery.
The TPS6205x family (TPS62050, TPS62051, TPS62052, TPS62054, TPS62056) are high‑efficiency synchronous step‑down DC/DC converters designed for battery‑powered devices such as cellular phones, PDAs, digital cameras and low‑power DSP supplies. They operate from 2.7 V to 10 V input and provide adjustable output from 0.7 V to 6 V or fixed options of 1.5 V, 1.8 V and 3.3 V, delivering up to 800 mA.
The devices feature internal N‑ and P‑channel MOSFETs, a soft‑start circuit, over‑temperature and over‑current protection, and can be synchronized to an external clock up to 1.2 MHz. They are offered in a 10‑pin MSOP (DGS) package and operate over a –40 °C to 85 °C temperature range.
| Input voltage range | 2.7 V to 10 V |
|---|---|
| Maximum output current | 800 mA |
| Efficiency | up to 95 % |
| Operating temperature range | -40 °C to 85 °C |
| Package | 10‑pin MSOP (DGS) |
| Synchronization clock range | 600 kHz to 1.2 MHz |
| Fixed output voltage options | 1.5 V, 1.8 V, 3.3 V |
| Adjustable output voltage range | 0.7 V to 6 V |
The devices can deliver up to 800 mA of output current.
They operate from 2.7 V to 10 V input.
Yes, it can be synchronized to an external clock signal up to 1.2 MHz.
