This manual covers the programming and operation of the Chroma 6300 series programmable power supplies. It includes detailed specifications, wiring and connection diagrams, and step‑by‑step programming procedures.
Key sections describe the load and noise characteristics, power and current ranges, available communication interfaces (GPIB, RS‑232), and LCD display functions, allowing users to configure the unit for constant voltage, constant current, constant resistance, or constant power modes.
| Power range | 20 W – 300 W |
|---|---|
| Current range | 0 A – 60 A |
| Voltage range | 2 V – 64 V |
The power rating ranges from 20 W up to 300 W depending on the model.
Current can be set from 0.6 A to 60 A, with various steps for different models.
