Chroma 6300 Programmable DC Electronic Load User Manual
The Chroma 6300 series is a programmable DC electronic load that can be configured with various load modules (e.g., 6304, 6301) and supports multiple operation modes such as constant current, constant resistance, constant voltage, and constant power. The system can be controlled locally via the front panel or remotely through GPIB or RS‑232 interfaces.
The manual describes safety precautions, warranty terms, module installation, connection methods, and detailed specifications. It also covers advanced features like external waveform control, dynamic load programming up to 20 kHz, and short‑circuit testing. This manual is written in Chinese.
Chroma 6300 specifications
| Power range | 20 W – 300 W |
|---|---|
| Current range | 0‑0.6 A – 0‑60 A |
| Voltage range | 2‑64 V (2‑60 V in CR mode) |
| Maximum dynamic load frequency | 20 kHz |
| Load modules per 6304 chassis | 4 |
Source: Chroma 6300 Programmable DC Electronic Load User Manual
All Chroma 6300 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Instruction set, parameters and examples for configuring or programming the device.
Questions answered in these manuals
How many load modules can the 6304 chassis accommodate?
The 6304 chassis can hold up to four load modules.
From: Chroma 6300 Programmable DC Electronic Load User Manual
What is the maximum frequency for the programmable dynamic load?
The programmable dynamic load can operate up to 20 kHz.
From: Chroma 6300 Programmable DC Electronic Load User Manual
What is the power rating of the Chroma 6300 series?
The power rating ranges from 20 W up to 300 W depending on the model.
What current settings are available on the Chroma 6300?
Current can be set from 0.6 A to 60 A, with various steps for different models.
