This manual introduces the features and usage of the Luminary Micro Stellaris LM3S6965 evaluation board.
The Stellaris LM3S6965 Evaluation Board is a compact evaluation platform for the LM3S6965 ARM Cortex‑M3 microcontroller. It features a fully integrated 10/100 Ethernet controller, an OLED graphics display, and a range of I/O breakout pads for rapid prototyping and debugging.
The board can be used as a standalone evaluation kit or as an in‑circuit debug interface (ICDI). In debug mode the on‑board MCU is bypassed, allowing external target programming via the standard 20‑pin JTAG/SWD connector or a USB debugging interface. The manual provides hardware descriptions, connection details, and schematics to help users get started quickly.
| Display | OLED graphics display, 128 × 96 pixel resolution |
|---|---|
| Debug connector | Standard ARM 20‑pin JTAG debug connector (input and output modes) |
| USB interface | USB cable provides serial communication, debugging, and power |
| MicroSD slot | MicroSD card slot |
| Speaker | Magnetic speaker |
| User I/O | User LED, navigation switches, select push‑buttons |
It includes an OLED graphics display with a resolution of 128 × 96 pixels.
A USB cable supplies serial communication, debugging, and power to the board.
It offers a standard 20‑pin ARM JTAG/SWD connector and a USB interface for debugging.
