This product is a single-supply operational amplifier with low offset voltage, low drift, low input bias current, high gain, high common mode rejection ratio and high power supply rejection ratio.
The LT1006 is a precision, single‑supply operational amplifier optimized for low offset voltage, low drift, and low supply current. It offers a wide input voltage range that extends to ground and can operate from a minimum supply voltage of 2.7 V.
The document lists absolute maximum ratings, detailed electrical characteristics for various package types (PDIP, plastic SO, metal can), typical performance curves, and package dimensions. It also includes notes on external resistor programming for supply‑current adjustment and optional offset‑nulling circuitry.
| Input Offset Voltage (typ) | 20 µV |
|---|---|
| Input Offset Voltage Drift (typ) | 0.2 µV/°C |
| Input Bias Current (typ) | 15 nA |
| Supply Current (typ) | 340 pA |
| Large‑Signal Voltage Gain (typ) | 2.5 M |
| Common‑Mode Rejection Ratio (typ) | 100 dB |
| Power Supply Rejection Ratio (typ) | 106 dB |
| Minimum Supply Voltage | 2.7 V |
| Maximum Output Voltage Swing (Low, No Load) | 15 mV |
The LT1006 can operate with a supply voltage as low as 2.7 V.
Typical input offset voltage is 20 µV.
Connecting an external resistor from Pin 8 to Pin 7 (or Pin 4) programs the supply current for low‑power or high‑speed operation.
Typical supply current is 340 pA.
