The document provides information about the features and characteristics of the ASUS P4BP-MX motherboard, including its power settings, connectors, and internal audio connectors.
This manual provides detailed guidance for installing the ASUS P4BP-MX motherboard, including preparation, component placement, and connection of cables and peripherals. Safety notices cover electrical and operational precautions to protect both the user and the hardware.
The document also explains BIOS setup options, driver installation procedures, and lists the motherboard’s key specifications such as supported CPUs, chipset details, memory capacity, expansion slots, audio and network features. Additional resources for firmware updates and ASUS support contacts are included. This manual is written in Chinese.
| CPU socket pins | 478 |
|---|---|
| Northbridge chipset | Intel 845GY |
| Southbridge chipset | Intel ICH4 (CEW82801DB) |
| Front‑side bus | 533/400 MHz |
| Expansion slots | PCI slots |
| Audio codec | Realtek 6‑channel audio codec |
| LAN controller | Realtek 10/100 Mbps Ethernet |
| USB support | USB 2.0 |
Use the EZ Flash BIOS or CrashFree BIOS utilities provided on the ASUS support website to flash a newer BIOS version.
