The HMP 130Y series includes five humidity and temperature transmitters (HMP 131Y‑135Y) that use a HUMICAP® sensor and a Pt 100 temperature sensor. The manual covers product description, installation, calibration, maintenance, technical data, accessories, and spare parts.
Key topics include output selection (4‑20 mA current or voltage), mounting recommendations, humidity measurement considerations, calibration procedures, and spare‑part lists. An appendix explains how to change output signals and calculate additional resistor values.
| Humidity measuring range | 0 – 100 %RH |
|---|---|
| Temperature sensor type | Pt 100 sensor |
| Default output current range | 4 – 20 mA |
| Output selection error after jumper change | < 0.15 %FS |
| Additional resistor accuracy for voltage output | ≥ 0.1 % |
The humidity range is 0 to 100 %RH.
A Pt 100 sensor is used for temperature measurement.
The default output is 4 to 20 mA for both temperature and humidity channels.
