This document introduces the features and characteristics of the product
This manual covers the features, specifications, and installation procedures for the Introducing A890GXM-A2Z motherboard. It includes detailed chapters on BIOS configuration, RAID setup, eJIFFY security, and troubleshooting common issues.
The document also lists the technical specifications such as supported processors, memory capacity, expansion slots, I/O ports, and integrated audio and networking components, helping users configure and maintain the system effectively.
| CPU socket | Socket AM3 |
|---|---|
| Memory slots | 4 x 240‑pin DDR3 DIMM sockets |
| Maximum memory | 32 GB |
| SATA ports | 5 x 6 Gb/s Serial ATA |
| USB ports | 12 USB 2.0, 2 USB 3.0 |
| LAN controller | Dual Realtek 8111DL Gigabit |
| Audio codec | ALC892 8‑Channel |
| Form factor | ATX (305 mm × 244 mm) |
The board includes five SATA ports, each capable of 6 Gb/s transfer rates.
The motherboard can accommodate up to 32 GB of DDR3 memory across four slots.
It uses an AMI BIOS with an 8 Mb SPI ROM.
