user's manual
The TForce 6100-939 is a Micro ATX motherboard that supports Socket 939 CPUs such as AMD Athlon 64 FX, Athlon 64, Athlon 64 X2 and AMD Sempron. It offers DDR266/333 memory up to 4 GB across two DIMM slots, SATA2.0 (3 Gb/s) and Ultra DMA IDE interfaces, as well as integrated audio (ALC655, 6‑channel) and LAN (RTL8201BL/CL). The board includes PCI Express x1 and x16 slots, four USB 2.0 ports, a VGA output, RJ‑45, PS/2, and various audio connectors.
The manual details hardware installation procedures, including CPU mounting, heatsink placement, and connector connections. It also explains how to update the BIOS using Biostar's AWDFLASH utility from a DOS prompt, and provides troubleshooting tips for common issues such as CMOS failures and invalid configurations. This manual is written in Japanese.
| CPU socket | Socket 939 |
|---|---|
| Supported CPUs | AMD Athlon 64 FX, Athlon 64, Athlon 64 X2, AMD Sempron |
| Memory type | DDR266/333 |
| Maximum memory | 4 GB |
| Form factor | Micro ATX |
| SATA support | SATA2.0, 3 Gb/s |
| LAN PHY | RTL8201BL / RTL8201CL |
| Audio codec | ALC655, 6‑channel output |
| USB ports | 4 USB 2.0 ports |
| VGA port | 1 |
| RJ‑45 port | 1 |
Download the AWDFLASH utility from Biostar's website, run it from a DOS prompt (e.g., "AWDFLASH.exe"), and follow the on‑screen instructions to update the BIOS.
The board supports Socket 939 CPUs, including AMD Athlon 64 FX, Athlon 64, Athlon 64 X2, and AMD Sempron processors.
It can accommodate up to 4 GB of DDR memory using two DIMM slots.
The motherboard includes four USB 2.0 ports.
