This guide provides step‑by‑step instructions for installing the ASUS GA-8IPE1000 motherboard, describing its layout, connector locations, and BIOS configuration. It also lists the supported CPUs, memory types, and expansion slots, helping users assemble a compatible system.
The document includes a Declaration of Conformity with EMC and safety standards, detailed diagrams of the board, and information on peripheral interfaces such as AGP, PCI, USB, SATA, and Ethernet. It is intended for system builders and technicians working with P4‑class platforms. This manual is written in Chinese.
| CPU socket | Socket 478 |
|---|---|
| Supported CPUs | Intel® Pentium®4 with HT Technology |
| Chipset | Intel 865PE HOST/AGP/Controller |
| Memory types | DDR400, DDR333, DDR266 DIMM |
| AGP slot | 4X/8X |
| PCI version | PCI 2.3 compliant |
| FireWire | IEEE1394 |
The board supports Intel® Pentium®4 processors with Hyper‑Threading technology.
It accepts unbuffered DDR400, DDR333, and DDR266 DIMM modules up to 4 GB.
The motherboard is built around the Intel 865PE HOST/AGP/Controller chipset.
Yes, it includes a Declaration of Conformity covering EN 55011, EN 61000‑3‑2, EN 55013, and related directives.
