These operating instructions describe how to use the German Pool Washer Dryer, including program selection, optional functions such as extra rinse, energic wash, prewash, and delay start, as well as how to operate the spin, dry and drying programs. Safety notes and fabric care guidelines are also provided.
Technical information such as dimensions, electrical requirements, heater and motor power, drum capacity, maximum load and spin speeds are listed, along with details on the appliance’s construction and compliance with relevant standards.
| Dimensions (H × W × D) | 850 mm × 595 mm × 537 mm |
|---|---|
| Weight | 66.0 kg |
| Electricity supply | 220‑240 V AC 50 Hz |
| Fuse rating | 13 A (BS1362) |
| Heater power | 2.1 kW |
| Motor power | 130 W |
| Pump power | 34 W |
| Water intake | Hot and cold fill or cold fill only |
| Drum capacity | 47 L (13.2 gal) |
| Maximum load | 6 kg |
| Spin speeds | 500 rpm / 1200 rpm |
| Mobility | 4 adjustable feet |
Turn the programme selector dial until the desired programme number aligns with the indicator mark, then press the start button.
The appliance can handle up to 6 kg of laundry per wash cycle.
Press the extra‑rinse button; the machine will add one more rinse to the selected programme.
