This document describes the features and characteristics of Haier brand products.
The manual describes Haier's flat‑type solar water heater, detailing its stainless‑steel water tank, vacuum glass collector tubes, and insulated frame. It explains the naming convention and the key specifications such as water capacity, collector area, and rated pressure.
The guide covers safety precautions, step‑by‑step installation, wiring, and mounting, as well as operation instructions, troubleshooting tips, warranty information, and after‑sales service contacts. It also includes recommendations for pressure boosting and proper orientation to ensure optimal performance. This manual is written in Chinese.
| Water tank material | SUS304 stainless steel |
|---|---|
| Nominal water capacity | 150 L (model 150) / 175 L (model 175) |
| Nominal collector area | 2.07 m² (model 150) / 2.48 m² (model 175) |
| Rated pressure | 0.05 MPa |
Install a water‑pressure boosting device to ensure normal water flow.
The heater should face true south with a deviation of +10° east or –15° west, keeping a clear distance from obstructions.
