The AD9388A is an integrated, multiformat, HDTV video decoder, RGB graphics digitizer, and 2:1 multiplexed HDMI/DVI interface.
The AD9382A is a single‑chip graphics digitizer and video decoder that supports a wide range of component and HDMI video formats, including 525i, 625i, 525p, 625p, 720p, 1080i, 1080p and 1250i. It provides up to 12 analog input channels, dual HDMI receivers, HDCP support, and can digitize RGB graphics up to UXGA (1600 × 1200 @ 60 Hz).
The device is supplied in a 144‑lead LFCSP package, operates from –40 °C to +85 °C, and includes multiple power rails (AVDD, DVDD, DVDDIO, PVDD, TVDD, CVDD). Detailed electrical characteristics, timing specifications, and pin configurations are provided for system designers.
| ADC resolution | 10 bits |
|---|---|
| Operating temperature range | –40 °C to +85 °C |
| Maximum HDMI receiver frequency | 225 MHz |
| Analog input channels | 12 |
| AVDD supply voltage | 1.71 V to 1.89 V |
| Power‑down current | 11.6 mA |
| Power‑up time | 25 ms |
The device operates from –40 °C to +85 °C.
The AD9388A provides 12 analog input channels through its multiplexer.
The HDMI receiver can handle frequencies up to 225 MHz.
