This manual is used to guide you on how to correctly use ECOM S2516G Smart Ethernet Switch. It mainly introduces the hardware features, installation process, configuration methods and management and maintenance of the switch.
This manual describes the features and hardware specifications of the ECOM S2516G intelligent Ethernet switch, a 16‑port Gigabit switch developed by Longwei Technology. It explains how to connect the device, configure network settings via the web interface, and manage advanced functions such as VLANs, LACP, RSTP, IGMP snooping, and QoS.
The guide also covers routine maintenance, troubleshooting common issues, firmware upgrades, and how to back up or restore configuration files. Detailed step‑by‑step procedures are provided for initial installation, IP address configuration, and testing connectivity with ping commands. This manual is written in Chinese.
| Number of ports | 16 10/100/1000M RJ45 ports |
|---|---|
| Switching capacity | 32 Gbps |
| Power input | 100 V ~ 240 V AC, 50/60 Hz |
| Operating temperature | 0 °C – 40 °C |
| Dimensions | 440 mm × 180 mm × 440 mm |
| LED indicators | Power, link/act, speed for each port |
The default management IP address is 192.168.2.1.
Select the “恢复出厂配置” (Restore Factory Settings) menu item and confirm the reset.
Use the ping command in a command prompt, e.g., `ping 192.168.2.1`, to verify connectivity.
