The manual begins with important safety precautions: place the fax machine on a stable, flat surface, keep it out of direct sunlight or extreme heat, avoid compressing the power cord, and do not share the power outlet with high‑power appliances. If the unit is exposed to water, unplug it immediately and contact an authorized SANYO service center; do not power it on again.
Before use, unpack the machine, remove protective foams and transport tape, and verify that all accessories (telephone line, thermal paper, instruction booklet) are present. The guide describes each part of the device—including the document feeder, paper tray, control panel, and sensor locations—and explains functions such as automatic document feeding, multiple resolution modes, and built‑in caller ID. Operating instructions cover paper loading, dialing, and using the memo‑print feature. This manual is written in Chinese.
| Model | SFX-A200 / SFX-A220 |
|---|---|
| Type | Desktop fax machine |
| Paper size | 216 mm × 30 m / 25 m |
| Effective scan width | 208 mm |
| Transmission speed | 9600/7200/4800/2400 BPS |
| Dimensions (W × H × D) | 337 mm × 104 mm × 255 mm |
| Weight | ≈ 3 kg |
| Operating temperature | 5 °C – 35 °C |
Immediately unplug the power and contact an authorized SANYO service center; do not power the machine on again.
It uses 216 mm wide thermal paper rolls, available in 30 m or 25 m lengths.
Four resolution modes are provided: standard, fine, ultra‑fine, and intermediate.
