The ISL1572 is a dual operational amplifier designed for PLC line driving in OFDM and SSC based solutions. This device features a high drive capability of 750mA while consuming only 6mA of supply current per amplifier and operating from a single 4.5V to 12V supply. The driver achieves a typical distortion of -80dBc, at 150kHz into a 25Ω load. The ISL1572 is available in the thermally-enhanced 16 Ld QFN or 10 Ld HMSOP package and is specified for operation over the full -40°C to +85°C temperature range. The ISL1572 has control pins BIAS0 and BIAS1 for controlling the bias and enable/disable of the outputs. These controls allow for lowering the power to fit the performance/power ratio for the application.
The ISL1572 is a dual operational amplifier designed for Power Line Communication (PLC) line driving in OFDM and SSC solutions. It operates from a single 4.5 V to 12 V supply and offers high drive capability while consuming only 6 mA per amplifier.
Key features include 21 dBm output power, up to 750 mA drive current, low quiescent current, wide bandwidth, and RoHS‑compliant packaging. Ordering information and package options are listed, and the device includes bias control pins for power management.
| Output power capability | 21 dBm |
|---|---|
| Maximum drive current | 750 mA from +12 V |
| Quiescent current per amplifier | 6 mA |
| Supply voltage range | 4.5 V to 12 V |
| Typical driver output distortion (10 MHz) | -80 dBc |
| Bandwidth | 250 MHz |
The ISL1572 can deliver up to 21 dBm output power.
It operates from a single 4.5 V to 12 V supply.
Each amplifier draws a low quiescent current of 6 mA.
