The Newman Ultra King Q60 series MP3 player is a powerful and easy-to-use multimedia player that supports MP3, WMA, AVI and other audio and video formats. It has a built-in speaker, can realize multi-tasking operation, supports timing shutdown, USB interface for quick reading and writing, high-speed data transmission, and firmware upgrades to expand the functions of the machine.
This manual introduces the Newman Q60 Series MP3 player, describing its 2.4‑inch high‑resolution TFT display, supported audio and video formats, and built‑in features such as EQ, A‑B repeat, recording, and image viewing. It guides users through basic operation, menu navigation, and battery management to ensure reliable use.
The document also contains detailed functional explanations, troubleshooting tips, and a technical specifications section that lists screen size, supported formats, storage options, output power, and other key parameters. This manual is written in Chinese.
| Screen size | 2.4‑inch 26‑color QVGA TFT |
|---|---|
| Video format | AVI |
| Audio formats | MP3, WMA |
| MP3 bitrate | 32Kbps–320Kbps |
| WMA bitrate | 48Kbps–320Kbps |
| Maximum output power | 10mW (L) + 10mW (R) |
| Frequency range | 20 Hz – 20 kHz |
| Signal‑to‑noise ratio | ≥85 dB |
| Dimensions | 88 mm × 51 mm × 9 mm |
| Internal storage | 256 MB / 512 MB / 2 GB |
| Supported image format | JPEG |
| Supported e‑book format | TXT |
| Supported lyric format | LRC |
| Supported recording format | WAV |
| Battery type | Built‑in lithium‑ion |
