Newman Jingyinwang N09 series MP3 player user manual, supports MP3, WMA music formats, built-in speaker, lyrics synchronization display, provides 3D surround sound, bass, customizable EQ and other shocking sound effects and repeat modes, powerful data manager, can realize file browsing, playback, deletion and other functions
This manual introduces the Newman N09 Series MP3 player, covering its features such as a 2.0‑inch TFT color screen, support for MP3/WMA audio, AVI video playback, and built‑in recorder. It explains basic operation, menu navigation, and how to manage files, images, and e‑books.
Detailed sections describe battery management, charging methods, troubleshooting tips, and the full technical specifications, helping users get the most out of the device and maintain its performance. This manual is written in Chinese.
| Dimensions | 78 mm×48 mm×11 mm |
|---|---|
| Video format | AVI |
| Audio formats | MP3, WMA |
| MP3 bitrate | 32Kbps–320Kbps |
| WMA bitrate | 48Kbps–320Kbps |
| Display | 2.0‑inch 260,000‑color TFT (220×176) |
| Memory options | 256 M / 512 M / 1 G / 2 G |
| Maximum output power | 10 mW (L) + 10 mW (R) |
| Signal‑to‑noise ratio | ≥85 dB |
| Battery | Built‑in Li‑ion |
Long use or frequent file deletions can fragment the internal flash memory, slowing the player; formatting the storage resolves the issue.
Turn the power switch to OFF, wait two minutes, then turn it back on; if it still won’t start, connect it to a computer or charger to activate the battery before trying again.
The player’s maximum output is 10 mW per channel, which works best with headphones of 50 Ω or lower impedance; higher‑impedance headphones may sound weak or distorted.
Battery life varies with ambient temperature, volume level, backlight, recording, and special sound effects; using the device in moderate temperature and moderate settings extends standby time.
