This manual introduces the basic usage methods of O2 Xda Zinc phone, including the function description of the phone components, installation of SIM/USIM card and battery, battery charging, power on, use of stylus, screen calibration, etc.
This manual guides users of the O2 Xda Zinc Pocket PC phone through initial setup, basic operation, and advanced features. It includes sections on device components, charging, and using the QWERTY keyboard and touch screen.
Key topics cover input methods, phone calling, wireless networking (Wi‑Fi, Bluetooth, infrared), multimedia functions (camera, video, audio), system settings, and a list of pre‑installed applications. Safety and regulatory information are provided in the appendix. This manual is written in Chinese.
| Processor | Intel PXA270 520 MHz |
|---|---|
| Operating System | Microsoft Windows Mobile 6.0 Professional |
| Flash ROM | 128 MB |
| RAM | 64 MB |
| Display | 240 × 320 TFT touchscreen, 65,536 colors |
| GSM Bands | 900/1800/1900 MHz |
| WCDMA Band | 2100 MHz |
| Wi‑Fi | 802.11b/g |
| Bluetooth | V2.0 |
| Infrared | SIR |
| USB | USB Client 1.1 |
| Camera | 2‑megapixel CMOS with flash |
| Battery | 1300 mAh Li‑ion |
| Talk Time (GSM) | 6 hours |
| Talk Time (WCDMA) | 4.8 hours |
| Charging Time | 3.5 hours (sleep mode) |
| Expansion Slot | MiniSD |
| Headphone Jack | 2.5 mm |
| Dimensions | 109 × 58 × 226 mm |
| Weight | 175 g (incl. battery) |
| Keyboard | Slide‑out QWERTY |
Charging the phone takes about 3.5 hours when the device is in sleep mode.
If you notice interference with a pacemaker or other medical equipment, turn the phone off immediately and consult the device’s manufacturer.
The phone can be connected via its USB client 1.1 port or using the infrared (IR) function.
It supports Wi‑Fi (802.11b/g), Bluetooth V2.0, and infrared (SIR) for data transfer.
