This document is about the registration and support information for the Philips DS7510 speaker. The speaker has a nominal output power of 10W RMS and a signal-to-noise ratio of 65dB. It can be connected to audio devices through MP3 link. The speaker is powered by an AC power adapter, which supports 100-240V input voltage. The dimensions of the speaker are 311 x 111 x 37.6mm, and the weight is not mentioned.
This guide introduces the Philips DS7510 audio system, showing how to register the product, connect it to iPod or iPhone devices, and safely operate it. Safety symbols, environmental disposal instructions and warranty notes are included.
Technical specifications such as power output, signal‑to‑noise ratio, power‑adapter requirements and physical dimensions are listed, along with usage tips for optimal performance.
| Rated Output Power | 10 W RMS |
|---|---|
| Signal‑to‑Noise Ratio | 65 dB |
| MP3 Link | 0.8 V RMS, 10 kΩ |
| Input Voltage | 100‑240 V~50‑60 Hz |
| Output Voltage / Current | 9 V 2000 mA |
| Operation Power Consumption | < 18 W |
| Eco Standby Power Consumption | < 1 W |
| Dimensions (Main Unit) | 311 × 111 × 37.6 mm |
| Weight (Main Unit) | 0.28 kg |
Register the product at www.philips.com/welcome to receive support and warranty information.
The system consumes less than 18 W while operating.
