Bose® FreeSpace® DS 100SE is a high-performance wall-mount speaker designed for a wide range of commercial applications. It has a power of 100W and a maximum installation height of 10m. It can be installed horizontally or vertically and has a stylish design. It meets global broadcasting and emergency system safety standards.
The Bose FreeSpace DS 100SE is a high‑performance surface‑mounted loudspeaker designed for venues such as retail stores, restaurants and hotels. It can be installed horizontally or vertically, supports both 8 Ω and 70 V/100 V operation, and complies with global safety standards.
This guide provides step‑by‑step installation instructions, key technical specifications, safety guidelines, a parts list, warranty information and measurement procedures to help users achieve optimal acoustic performance. This manual is written in Chinese.
| Maximum Power | 100 W |
|---|---|
| Impedance | 8 Ω (also 70 V/12.5 W, 25 W, 50 W, 100 W) |
| Sensitivity | 85 dB SPL (1 W @ 1 m) |
| Frequency Range | 65 Hz – 16 kHz (-3 dB) |
| Dispersion Angles | Horizontal 180° × Vertical 75° (-6 dB average 1‑4 kHz) |
| Tweeter Size | 2.25 in (57 mm) |
| Woofer Size | 5.25 in (133 mm) |
| Speaker Dimensions | 216 mm × 381 mm × 178 mm (Depth × Width × Height) |
| Weight | 6.4 kg (7.7 kg packaged) |
| Warranty | 5 years |
The DS 100SE is rated for a maximum power of 100 W.
It can be used with an 8 Ω impedance or in 70 V/12.5 W, 25 W, 50 W, and 100 W configurations.
The speaker provides a horizontal dispersion of 180° and a vertical dispersion of 75° (‑6 dB average 1‑4 kHz).
The DS 100SE comes with a five‑year warranty.
