This instruction manual introduces the features and characteristics of the JENOPTIK 4100z3, including system requirements, installation instructions, and operating instructions.
This manual covers everything you need to get started with the JENOPTIK JD4100z3 zoom camera, from unpacking and battery installation to using the various shooting modes and playback functions. Detailed sections explain the camera’s controls, menu system, and how to connect the device to a computer.
Additional chapters provide technical specifications, safety guidelines, cleaning and storage recommendations, and troubleshooting tips to help you maintain optimal performance and avoid common issues.
| Image Sensor | 1/1.75 inch interline CCD, 4,133,856 pixels |
|---|---|
| Effective ISO | ISO 100 (single ISO sensitivity) |
| Lens Focal Length | 8–24 mm (38–114 mm equivalent) |
| Maximum Aperture | F3.4–F3.6 |
| Shutter Speed Range | 1/500 s to 1 s |
| Storage Media | CF (Type 1) card, up to 8 MB shown in specs |
| Image Size (Full) | 2272 × 1704 px |
| Operating Temperature | 0 °C to 40 °C |
The camera uses four AA‑size alkaline batteries or four AA Ni‑MH rechargeable batteries; AA lithium batteries are not supported.
The camera is designed to operate between 0 °C and 40 °C (32 °F to 104 °F).
Approximately two full‑size images can be stored on an 8 MB CF card in Fine (Standard) mode.
No, the camera is neither waterproof nor splash‑proof; using it with wet hands or near water can cause damage.
