AD8565/AD8566/AD8567 are low cost, single-supply, rail-to-rail input and output operational amplifiers optimized for LCD monitor applications. They are built on an advanced high voltage CBCMOS process. The AD8565 contains a single amplifier, the AD8566 has two amplifiers, and the AD8567 has four amplifiers. These LCD op amps have high slew rates, 35 mA continuous output drive, low bias voltage and 10 mV output offset voltage, enabling high accuracy and low noise LCD driver applications.
The AD8565, AD8566, and AD8567 are low‑cost, single‑supply, rail‑to‑rail input and output operational amplifiers optimized for LCD reference drivers, portable electronics, and communications equipment. They offer high slew rates, 35 mA continuous output drive, 250 mA peak output drive, and low offset voltages.
Key specifications include a supply voltage range of 4.5 V to 16 V, continuous output current of 35 mA, peak output current of 250 mA, offset voltage of 10 mV, and a slew rate of 6 V/µs. The devices are offered in several surface‑mount packages: AD8565 in a 5‑lead SC70, AD8566 in an 8‑lead MSOP, and AD8567 in 14‑lead TSSOP and 16‑lead LFCSP.
| Supply Voltage Range | 4.5 V to 16 V |
|---|---|
| Continuous Output Current | 35 mA |
| Peak Output Current | 250 mA |
| Offset Voltage | 10 mV |
| Slew Rate | 6 V/µs |
The devices operate from 4.5 V up to 16 V supply voltage.
Each amplifier can source a continuous output current of 35 mA.
The typical offset voltage is 10 mV.
