This is a PCB drawing of a motherboard, which shows the components and interfaces of the motherboard.
This manual covers the ASUS TUA266 Socket 370 motherboard, detailing its features, hardware installation steps, BIOS configuration, and software installation. It includes safety notices, part lists, and troubleshooting information.
The document is organized into sections such as Features, Hardware Installation, BIOS Setup, Software Installation, and an Appendix with connector definitions and specifications. This manual is written in Chinese.
| Expansion Slots | AGP Pro slot, PCI bus, UltraDMA/100/133, USB |
|---|
It includes an AGP Pro slot, standard PCI bus slots, UltraDMA/100/133 IDE channels, and USB ports.
