This document is the user manual for Rev. A+ System Board, which provides information on how to use the system board and precautions. The system board is compatible with operating systems such as Windows 98 SE, Windows ME, Windows 2000, Windows NT 4.0, and Windows XP. It features Intel's Pentium 4 and Celeron processors and offers high reliability.
This manual provides detailed information about the Infinity 865PE system board, including safety precautions, hardware layout, BIOS configuration, and supported components. It also explains how to install the board, connect peripherals, and perform basic troubleshooting.
The document includes specifications for the Intel 865PE chipset, supported processors, memory configurations, AGP and PCI slots, audio codec, and power‑management features, as well as step‑by‑step instructions for BIOS updates and system setup.
| Chipset | Intel 865PE |
|---|---|
| CPU Socket | Socket 478 |
| Supported Processors | Intel Pentium 4 (800 MHz/533 MHz FSB), Pentium 4 Northwood, Intel Celeron Northwood |
| Memory Slots | Four 84‑pin DDR DIMM sockets, dual‑channel |
| Maximum Memory | 4 GB |
| Supported DDR Types | PC2100/PC2700/PC3200 (DDR266/DDR333/DDR400) |
| PCI Slots | 5 PCI slots |
| Audio Codec | C‑Media CMI9739a 6‑channel, 20‑bit stereo full‑duplex |
Unplug the power cord before removing the system chassis cover for installation or servicing.
The board provides four 84‑pin DDR DIMM sockets.
Supported processors include Intel Pentium 4 with Hyper‑Threading, Pentium 4 Northwood, and Intel Celeron Northwood.
