Dell Inspiron Advanced Port Replicator User's Guide

About this manual

This guide provides step‑by‑step instructions for attaching external devices to the Advanced Port Replicator (APR), connecting the computer, and using the docking and undocking functions. It also includes safety notices, connector descriptions, and regulatory information.

Key sections cover the APR I/O connectors, controls and indicators, wiring diagrams, technical specifications, and warranty details, helping users set up a desktop environment quickly and safely.

What's inside

• APR I/O Connectors
• APR Controls and Indicators
• Connecting External Devices to the APR
• Connecting the Computer to the APR
• Docking the Computer
• Undocking the Computer
• Technical Specifications
• Regulatory Notices
• Warranty and Return Policy

Specifications

Frequently asked questions

What AC adapter should be used with the Advanced Port Replicator?

Use the Dell AC adapter that came with the APR, model number PA‑6.

How many USB devices can be connected to the APR?

One or two USB devices can be connected to the dual USB connectors.

Which connector is used for an external monitor?

The video connector on the side of the APR is used for an external monitor.
