Introduces the characteristics and features of Intel® Desktop Board DQ965GF
This product guide covers the Intel DQ965GF desktop board, detailing its features, supported components, and compliance requirements. It includes chapters on board features, installation and replacement of components, BIOS updating, RAID configuration, error messages, and regulatory compliance.
The guide is intended for technically qualified personnel and provides detailed tables, diagrams, and step‑by‑step instructions for setting up the board in a PC environment, along with safety and EMC guidelines.
| Form Factor | microATX (243.84 mm × 243.84 mm) |
|---|---|
| Processor Support | Intel® processor in LGA775 package |
| Chipset | Intel® Q965 Express (GMCH + ICH8DO) |
| Graphics | Intel® Graphics Media Accelerator 3000 |
| USB Ports | Up to 10 USB 2.0 ports (6 back‑panel, 4 via headers) |
| SATA | Six SATA 3.0 Gb/s channels (one device per channel) |
| LAN | Gigabit (10/100/1000 Mb/s) using Intel® 82566DM |
| RAID Support | Intel® Matrix Storage Technology |
It provides up to 10 USB 2.0 ports, with six on the back panel and four routed to internal headers.
The board uses a microATX form factor measuring 243.84 mm × 243.84 mm.
Yes, it supports RAID through Intel® Matrix Storage Technology.
