KEB F5-MULTI / SERVO Service Manual

This manual is the operating manual for KEB COMBIVERT F5-MULTI / SERVO 2.7. It introduces the product's functions, features, usage methods, parameter configuration, operation and maintenance

Brand: KEB
Category: Motor
Document type: Service Manual
Language: English
Pages: 228
File format: PDF
File size: 12.6 MB
Published: 21 March, 2012
Updated: 30 September, 2023
MD5 checksum: D52B64A28294A8379E3EC64C97EAF115
PDF: KEB F5-MULTI / SERVO Service Manual PDF

About this manual

This manual covers the complete functional description of the KEB COMBIVERT F5-MULTI / SERVO drive, including hardware specifications, analog and digital I/O, set‑point and ramp configuration, motor data, protective functions, start‑up procedures, special functions, encoder interface, error assistance, project planning and network integration. It also contains an annex with additional reference material.

Contact information for KEB worldwide locations is provided at the end of the document, allowing users to obtain technical support and service from KEB subsidiaries in Germany, Austria, Belgium, the United Kingdom, Italy, Japan, the Netherlands, Portugal, Taiwan, Sweden, China, the United States and other regions.

What's inside

Introduction
Summary
Hardware
Analog Inputs and Outputs
Digital Inputs and Outputs
Setpoint and Ramp
Parameter Adjustment
Voltage/Frequency Characteristic Adjustment
Functions
Motor Data and Controller

Specifications

Part number	00.F5.MEA-K270

Frequently asked questions

What is the part number of the KEB COMBIVERT F5-MULTI / SERVO?

The part number is 00.F5.MEA‑K270.
