This manual introduces the LCD19M12 television, describing its slim design, built‑in speakers, multiple video inputs, and energy‑saving features. It also outlines safety precautions, proper handling, and environmental considerations.
Detailed sections cover signal source selection, remote‑control battery installation, antenna and peripheral connections, installation of the base, and a full list of technical specifications such as resolution, power consumption, and supported video formats. This manual is written in Chinese.
| Maximum resolution | 1440 x 900 |
|---|---|
| Best working resolution | 1440 x 900 @ 60 Hz |
| Pixel pitch | 0.2835 mm × 0.2835 mm |
| Viewable area | 408.24 mm × 255.15 mm |
| Color depth | 16.7 million colors |
| Audio output power | 3 W + 3 W |
| Input voltage range | 100 V‑240 V, 50/60 Hz |
| Maximum stored channels | 200 |
| Dimensions (unpacked) | 552 mm × 383 mm × 73 mm |
| Weight (unpacked) | 5.5 kg |
Open the battery compartment, insert two AAA (7 V, 1.5 V) cells, making sure the polarity matches the “+” and “–” markings.
The manual recommends using the 1440 × 900 @ 60 Hz mode for optimal display performance.
The television can store up to 200 channels.
The TV complies with EPA Energy‑Star and ESA DPMS standards, offering standby mode with reduced power consumption.
