This manual covers everything needed to install and use the Sampo ES‑D13S/ES‑D14S/ES‑D15S front‑load washing machines. It begins with installation precautions, leveling adjustments, and water‑inlet connection, then details the installation steps and required site conditions. The control‑panel operation section explains each button, indicator, and the various wash programs such as standard, strong, memory, soak, light‑sweat, and combined drying cycles.
Additional sections describe routine cleaning, maintenance, safety warnings, troubleshooting of common faults, and the technical specifications of the machines. The document also includes warranty and service‑protection information. This manual is written in Japanese.
| Power Consumption | 280 W / 290 W / 310 W |
|---|---|
| Voltage / Frequency | 110 V / 60 Hz |
| Wash Type | Impeller (渦推式) |
| Machine Weight | 53 kg |
| Standard Water Usage | ≈285 L per standard cycle |
| Dimensions (W×D×H) | 642 mm × 657 mm × 1023 mm |
| Maximum Load Capacity | 13 kg / 14 kg / 15 kg |
| Inlet Water Temperature Range | 5 °C – 35 °C |
