The Joyoung JYDZ-16A/B is a fully‑automatic home soymilk maker that grinds, heats, filters and keeps soy milk warm with micro‑computer control. It offers two programs – “Rich‑Fiber Soymilk” and “Rich‑Flavor Soymilk” – and completes a batch in about ten minutes.
The manual is organized into chapters covering components and their names, step‑by‑step operating instructions, technical specifications, safety precautions, and a troubleshooting guide. It also includes parts lists, cleaning procedures, and warranty information. This manual is written in Chinese.
| Rated Voltage | 220 V~ |
|---|---|
| Rated Frequency | 50 Hz |
| Motor Power | 180 W |
| Heating Power | 800 W |
| Dimensions (L×W×H) | 249 mm × 178 mm × 284 mm |
| Net Weight | 2.1 kg |
| Dry Bean Capacity | 75 ± 5 g |
| Water Capacity | 1100 – 1300 ml |
Soak beans for 8–16 hours in spring/autumn, 6–10 hours in summer, and 10–16 hours in winter for northern regions; adjust accordingly for southern regions.
A spill‑prevention electrode detects the first boil and activates intermittent heating to keep the soymilk from overflowing.
