The Haier CXW-209-J86 is a stainless‑steel range hood intended for kitchen ventilation. This guide describes the hood’s components, safety precautions and technical specifications.
It contains step‑by‑step procedures for installing the unit, using the control keys, cleaning the filter and lamp, performing regular maintenance, and resolving common problems. This manual is written in Chinese.
| Motor input power | 209 W |
|---|---|
| Illumination lamp rating | 12 V 20 W |
| Air flow pressure | > 220 Pa |
| Sound power level (A‑weighted) | 69 dB |
The distance from the stove surface to the bottom of the hood should be 550 mm to 700 mm.
