The document is a certificate of quality for the CXW-199-DS63 product, confirming its excellent quality characteristics.
This manual covers the Haier CXW-199-DS63 kitchen range hood, describing its main components, safety warnings, and technical specifications. It is intended for users and installers in mainland China.
The document is organized into sections on safety precautions, installation methods, operating controls (speed, lighting, timer), regular cleaning and maintenance, service information, and detailed technical parameters. Troubleshooting tips and a parts list are also included. This manual is written in Chinese.
| Motor input power | 193 W |
|---|---|
| Lighting lamp power | 15 W × 2 |
| Power supply voltage | 220 V |
| Rated frequency | 50 Hz |
| Maximum back pressure | 300 Pa |
| Sound pressure level | 54 dB |
| Net weight | 21 kg |
Use an impact drill with a 8 mm drill bit to make five holes 50‑60 mm deep, fix the mounting brackets with M4×20 screws, attach the duct and secure the unit to the wall at a height of 650‑700 mm above the stove.
