This is a user manual for the convenience store refrigerated vertical cabinet Xiaowangzi GK0.7L5. It introduces the safety use, service record, operation instructions, circuit diagram, electrical operation, fault diagnosis, maintenance instructions, product instructions and other contents.
This manual covers safety information, proper installation procedures, and operating instructions for the Haier GK0.7L5 refrigerated display case used in convenience stores. It details required safety measures, component handling, and the steps needed to set up the unit correctly.
Technical parameters, wiring diagrams, and a comprehensive troubleshooting section are included to help service personnel diagnose and resolve common issues such as temperature setting errors, condenser problems, and controller faults. This manual is written in Japanese.
| Operating temperature | 0‑+5 °C |
|---|---|
| Unit weight | 270 kg |
| Packed weight | 328 kg |
Lower the temperature setting or adjust the thermostat to a lower value.
Check the controller for a short circuit; if faulty, replace the controller and verify all terminal contacts.
