This manual explains how to install and safely operate the Haier BCD-588WS refrigerator. It includes safety warnings, power‑connection requirements, and instructions for using features such as the semi‑automatic ice maker, fresh‑food box, and adjustable shelves.
Technical data such as power consumption, capacity, dimensions, and wiring diagrams are listed, along with detailed guidance on temperature adjustment, lighting replacement, and after‑sales service procedures. This manual is written in Chinese.
| Model | BCD-588WS |
|---|---|
| Input Power | 180 W |
| Rated Power | 250 W |
| Annual Energy Consumption | 1.38 kWh/24h |
| Refrigerant | R134a (170 g) |
| Total Capacity | 580 L |
| Freezer Capacity | 180 L |
| Weight | 180 kg |
| Dimensions (D×W×H) | 770 mm × 910 mm × 1770 mm |
| Rated Voltage | 220 V~ |
| Frequency | 50 Hz |
Turn off the power, press the release tab to remove the lamp holder, rotate the bulb counter‑clockwise, replace it with a 25 W E14 lamp, then re‑insert the holder.
Use a dedicated 220 V/50 Hz grounded outlet, ensure the power cord is connected to a three‑wire grounded socket, and avoid voltage fluctuations outside 187‑242 V.
