LRC5141, LRC5142, LRC5143 LON DALI Light Controller Installation instructions. This document provides installation instructions, including installation steps and connection methods.
This document provides step‑by‑step installation instructions for the Philips LRC5141, LRC5142 and LRC5143 LON‑DALI light controllers. It includes wiring diagrams, connector types, and recommended cable lengths for the LightMaster Modular LON‑DALI system.
The guide also lists the required power supplies, operating voltage ranges, and environmental limits, as well as the Philips‑specific order types for branching connectors, extension cables and sensor cables.
| Auxiliary voltage | +5V DC |
|---|---|
| Connector type | RJ‑12 (6p/6c) Telejack |
| Maximum cable length | 35 m |
| Input voltage (mains) | 230 V ~ 50/60 Hz |
The LRC5143 can be connected with a cable up to 35 m long.
The LRC5141 uses an RJ‑12 (6‑pin/6‑contact) Telejack connector.
