This document describes the features and performance of the Siemens wind turbine SWT-2.3-93. The wind turbine has outstanding efficiency and reliability, suitable for various applications. It features advanced aerodynamic design and special blade manufacturing process, as well as high-performance gearbox and generator system.
This manual describes the overall design of the SWT‑2.3‑93 wind turbine, including its three‑blade rotor, B45 integral blade, gearbox, generator, yaw system, and control architecture. It explains how the turbine automatically starts at low wind speeds, adjusts blade pitch and rotor speed for optimal power output, and shuts down safely in extreme conditions.
The document also covers remote monitoring via the WebWPS SCADA system, a network‑based condition monitoring (TCM) system, and power conversion using the NetConverter module. Maintenance procedures, safety features, and technical specifications such as rated power, voltage, and wind‑speed limits are provided for operators and service personnel. This manual is written in Chinese.
| Rated power | 2300 kW |
|---|---|
| Rated wind speed | 13‑14 m/s |
| Rotor speed range | 6‑16 rpm |
The turbine automatically starts and runs when the average wind speed reaches 3‑5 m/s.
The turbine is equipped with the WebWPS SCADA system for remote control and status viewing via a standard web browser.
When the average wind speed exceeds 25 m/s, the blades feather and the turbine shuts down automatically.
It uses a cage‑rotor, fully enclosed asynchronous generator that does not require a collector ring.
