SWT-3.6-107 wind turbine is the largest in the Siemens wind power product series, designed for offshore applications. Its rotor diameter is 107 meters, with a swept area of 9000 square meters. The advanced aerodynamic technology of the integral blade (B52 IntegralBlade®) has brought power output to a new level.
This manual describes the Siemens SWT‑3.6‑107 wind turbine, the largest model in Siemens’ offshore wind product line. It covers the turbine’s overall design, key components such as the three‑blade rotor, pitch system, gearbox, generator, yaw system and tower, and explains the integrated NetConverter power conversion system.
Operational features include automatic start at low wind speeds, variable‑speed and variable‑pitch control, remote monitoring via the WebWPS SCADA system, and grid‑compatibility functions such as voltage/frequency control and fault‑ride‑through capability. Technical specifications, cabin configuration, and safety systems are also provided. This manual is written in Chinese.
| Rated Power | 3,600 kW |
|---|---|
| Generator Voltage | 690 V |
| Rotor Diameter | 107 m |
| Swept Area | 9,000 m² |
| Rotor Speed | 5‑13 rpm |
| Cut‑in Wind Speed | 3‑5 m/s |
| Rated Wind Speed | 13‑14 m/s |
| Cut‑out Wind Speed | 25 m/s |
| Maximum Gust Speed (3 s) | 55 m/s (standard) / 70 m/s (IEC) |
| Blade Length | 52 m |
The turbine is rated at 3,600 kW.
It uses the WebWPS SCADA system, which provides remote control and status views through a standard web browser.
