The FIBOX CAB QUICK, CABQ and SPACE LINK series are modular sealing boxes made from polycarbonate and ABS, offering IP65 and IK08 protection. The manual describes the basic configuration, material options, and the range of dimensions available for each model.
Installation instructions cover mounting options, adjustable depth brackets, and the use of EPDM sealing gaskets. Technical specifications, safety standards (EN 60529, UL94‑5W, RAL 7035) and accessory part numbers are also listed. This manual is written in Chinese.
| Material | Polycarbonate and ABS |
|---|---|
| IP Rating | IP65 |
| IK Rating | IK08 |
| Typical Dimension (example model) | 300 mm × 200 mm |
| Standard Compliance | EN 60529, UL94‑5W, RAL 7035 |
They are constructed from polycarbonate and ABS plastic.
The boxes are rated IP65 for ingress protection and IK08 for impact resistance.
One common size is 300 mm by 200 mm, with other dimensions listed in the technical data tables.
