The content of this document contains some garbled characters, and it is impossible to analyze the specific features and characteristics of the product.
This manual covers important safety precautions for using the LS22A13W television, including temperature and humidity limits, handling warnings, and proper ventilation. It also explains how to operate the remote control, adjust picture‑in‑picture, and configure audio settings.
Installation instructions describe VESA‑compatible mounting, connector types (RCA, S‑VHS, DVI) and wiring diagrams. The final section lists the TV’s technical specifications such as power consumption, dimensions, and audio performance. This manual is written in Japanese.
| Maximum Power Consumption | 120 W |
|---|---|
| Dimensions (W × H × D) | 23.62 × 26.3 × 17.46 inches |
| Operating Temperature | 50 °F – 104 °F |
| Operating Humidity | 10 % – 80 % |
| Storage Temperature | -13 °F – 113 °F |
| Storage Humidity | 5 % – 95 % |
| Audio Input (RCA) Level | 0.5 Vrms (‑9 dB) |
| Headphone Output (Maximum) | 10 mW |
| Frequency Response (Speaker) | 80 Hz – 20 kHz |
| Speaker Output Power | 7 W × 2 |
The TV can operate safely between 50 °F and 104 °F.
The maximum power consumption is 120 W.
The remote control works up to about 7 meters from the TV.
The TV can be stored in humidity ranging from 5 % to 95 %.
