This is a product user manual, which introduces the functions and features of the product and how to use it.
This manual provides safety warnings, installation guidelines, and operating instructions for the Samsung HPL5025 plasma display. It includes detailed steps for wall mounting, remote‑control setup, and connecting external devices such as speakers, VCRs, DVD players, and PCs.
The document also lists the technical specifications of the display, including dimensions, weight, power requirements, and video/audio input options, as well as troubleshooting tips and warranty information.
| Display dimensions | 1208.5 mm (W) × 89 mm (D) × 724 mm (H) |
|---|---|
| Display weight | 42 kg (92.59 lb) |
| Voltage range | 100‑240 V, 60 Hz |
| Power consumption | 540 W |
| Screen size | 1106.5 mm (H) × 622 mm (V) (43.56 in × 24.49 in) |
| RGB input | Mini‑D‑SUB 15‑pin (RGB1) |
| Video input (analog) | 0.714 V, 75 Ω terminated |
The display operates on 100‑240 V, 60 Hz and consumes up to 540 W of power.
The remote works within a distance of 7–10 m and an angle of 30° from the receiver.
The warranty lasts one year from the date of purchase and does not cover damage caused by image retention.
