DKVM-L501/L508/L516 series is an intelligent switching control platform that integrates keyboard, mouse and display. It has the characteristics of improving efficiency, simple use, easy management, cost saving, remote management and environmental protection and energy saving.
This manual describes the DKVM-L501/L508/L516 series of LCD KVM intelligent control platforms, including their basic features, hardware dimensions and supported operating systems. It also details the integrated 15‑inch LCD, keyboard, mouse and video switching functions.
Installation procedures cover rack mounting, cable connections and power setup, while the usage section explains OSD menu navigation, scanning modes and key mappings. The document ends with common fault troubleshooting, maintenance tips, accessory list and environmental specifications. This manual is written in Chinese.
| 显示屏类型 | XGA TFT LCD |
|---|---|
| 显示屏大小 | 15 英寸 |
| 分辨率 | 1024*768 |
| 亮度 | 200-250 cd/m² |
| 对比度 | 600:1 |
| 功率 | 15W |
| 键盘设计 | 104 键 |
| 电源输入 | DC12V 4A 48W |
| 工作温度 | 0-60 °C |
If the power indicator is off, check the power cable; if it is red, check the video cable and ensure the computer is on; if it is green, check the line sync range.
Press Scroll Lock twice, then press the R key; the unit will automatically reset the screen, keyboard and mouse signals.
Close the LCD screen cover; the LCD power indicator turns red, indicating the screen is powered off.
