ASRock A780LM is an entry-level motherboard for small form factor PCs, featuring an AM4 socket, support for 2nd and 3rd Gen AMD Ryzen processors, DDR4 memory, and 6 SATA 6Gb/s ports and 1 M.2 slot for installing an SSD.
The ASRock AZ80r7 is a Micro‑ATX motherboard that supports AMD AM2+ and AM2 processors, dual‑channel DDR2 memory up to 8 GB, and a range of expansion slots. This quick installation guide provides step‑by‑step instructions for installing the CPU, memory modules, and expansion cards, as well as configuring SATA and LAN connections.
Safety precautions, BIOS setup, and supported operating systems (Windows XP and Vista, both 32‑ and 64‑bit) are also covered to help users achieve a stable system configuration. This manual is written in Chinese.
| Memory type | DDR2 1066/800/667/533 non‑ECC, un‑buffered |
|---|---|
| PCI Express slots | 1 x PCIe x1, 2 x PCIe x16 (PCI Express 2.0) |
| LAN | Gigabit Ethernet (10/100/1000 Mb/s) via Realtek RTL8111DL |
