The LW6 series universal conversion switch is suitable for AC 50 Hz, voltage up to 380 V. DC voltage up to 220 V and current up to 5 A for AC/DC circuits. It is mainly used for the conversion of electrical control circuit and electrical measuring instrument, as well as remote control of distribution equipment.
The LW6 series universal transform switch is designed for AC circuits up to 380 V at 50 Hz and DC circuits up to 220 V, with a current rating of 5 A. It is used for converting control lines, measurement instrument connections, and remote control of distribution equipment.
The manual lists technical data such as a 5 A rated contact current, coil power of 30 VA (AC) and 30 W (DC), an electrical life of 200 k cycles (AC) and 100 k cycles (DC), and a maximum operation frequency of 120 times per hour. Installation dimensions and mounting details are also provided. This manual is written in Chinese.
| Rated contact current | 5 A |
|---|---|
| Coil power (AC) | 30 VA |
| Electrical life (AC) | 200 000 cycles |
| Electrical life (DC) | 100 000 cycles |
| Maximum operation frequency | 120 times per hour |
The contacts are rated for a heating current of 5 A.
The coil can handle 30 VA in AC and 30 W in DC.
The switch may be operated up to 120 times per hour.
It supports AC up to 380 V (50 Hz) and DC up to 220 V.
