This manual explains how to install the Intel Pro/100+ network adapter on Windows 98 and Windows NT 4.0, including automatic detection, manual driver installation, and creating a driver disk. It also describes the use of the PROSet software for configuring and optimizing the adapter.
The appendix lists the adapter’s technical specifications such as PCI V2.2 compatibility, RJ45 interface, support for 10 Mbps/100 Mbps Ethernet, power consumption, operating temperature, humidity range, indicator lights, and safety certifications. This manual is written in Chinese.
| Compatibility | PCI V2.2 System |
|---|---|
| Network Interface | RJ45 |
| Supported Ethernet | 100Base TX Fast Ethernet |
| Power Consumption | 1.06 Watts @ 5.0 VDC |
| Transfer Rate | 10 Mbps or 100 Mbps |
| Operating Temperature | 0 °C – 55 °C |
| Humidity Range | 10 % to 90 % |
| Indicator Lights | Activity/Link, 100 Mbps |
| Safety Certification | UL |
| FCC Class | Class B |
| CE & Immunity | CE & Immunity |
You can use automatic detection by starting Windows 98 and following the “new hardware” dialog, or manually install the driver via the Control Panel’s Device Manager.
Open the Device Manager, select the Intel PROVZ100+ adapter, choose to update the driver, and point to the driver location on the floppy or CD.
The adapter supports Windows 95/98, Windows NT 4.0, Novell NetWare 3.1X/4.1X, and SCO UNIX.
The ACTVLNK light stays on when the link is active, the “常灭” light shows a 10 Mbps connection, the “100 常亮” light shows a 100 Mbps connection, and the flashing light indicates data transmission activity.
