This document is the user manual for WD800Y washing machine.
This manual covers safety precautions, installation requirements, and technical specifications for the Galanz WD800Y microwave/ grill oven, including power ratings, dimensions, and clearances. It also explains the control panel layout and the functions of each button and indicator.
Detailed operating procedures are provided for clock setting, power level selection, cooking programs (microwave, grill, combined modes), weight‑based cooking, quick start, multi‑stage cooking, and child‑lock activation. The guide includes cleaning, regular maintenance, and troubleshooting steps, as well as repair instructions for service personnel. This manual is written in Chinese.
| Microwave input power | 1300W |
|---|---|
| Microwave output power | 800W |
| Microwave frequency | 2450MHz |
| External dimensions (H×W×D) | 305mm × 508mm × 430mm |
| Cavity dimensions (H×W×D) | 215mm × 350mm × 330mm |
| Cavity capacity | 23L |
| Effective turntable area | 0.077m² |
| Effective cavity volume | 16L |
| Cavity material | sprayed zinc‑plated sheet |
| Net weight | ≈16.5kg |
Press and hold the “停止/取消” key for 3 seconds; a beep sounds and the child‑lock indicator lights up, disabling operation.
Leave at least 5 cm on each side of the oven and at least 10 cm behind the back panel.
